Click to expand.Apologies for this. My DM 800 Clone is actually Boot: #76 not #82. Can I still flash the image from the link you provided Or do I need to upgrade the bootloader from #76 to #82 first before installing the new image? How can I upgrade the bootloader?

PLUGIN ISTALLATI: LAN ATTIVATA potete rilevare il vostro ip del decoder con netscan.192.168.1.10 VHANNIBAL AUTOSETTING 1.2 aggiorna i setting in automatico.

I am trying to flash the latest image on DM800 Clone so that I can have 7 days EPG. I am trying to backup my current image file by using FlashWizard Pro 6.3 but When I click on 'Flash Image Backup' it shows 'Reading Jffs2 partition.' And nothing happens. Please can you tell me how can I backup my current image and bootloader using my PC?

Thanks in advance for your help. For your information you cannot upgrade bootloader from 76 to 82 as this will not work.

The bootloader in a dreambox is equivalent to bios in a computer. The bios must match the hardware config of the computer. Bootloader 82 is tied to the newer version of dreambox hardware. If you loaded this bootloader and then the associated image the box would crash. Note that bootloaders however are backward compatible. This means that you can load bootloader 72 on a bootloader 76 box but if you do so you limit the functionality of the box.

800

Ene til zhonundo irlar. So if you get a bootloader 76 box I suggest you load associated compatible images (ie. Ss76 images). The ss76 image you mention should work fine.

Thanks very much for your help & guidance. This is how I flashed latest DM 800-S HD Clone image/bootloader by the help of B16MCC from Dreamboxuk.com. I assume you are aware of how to flash a DM 800-S HD Clone by using web browser. 1) I am using DM 800-S HD Clone ( Boot/ssl #76, Sim: 2.0.1, image =The Gemini Project 2) 2) Flash latest bootloader/ssl (for DM 800 Clone) #84A first 3) Reboot 4) Flash below dreambxuk image (for DM 800 Clone). Your new image is ready to use. 6) If your image is not compatible with your bootloader you will not be able to flash the new image by using the web browser and will get below error CRC check skipped INVALID IMAGE (OR OLD VERSION) 7) You need to flash compatible bootloader first then the image.

8) I flashed new bootloader/image and everything is working fine for now. 9) I have 7 days graphical EPG now (thanks to this new image/bootloader) that is updated once a day and I do not need to go on the PC and look for TV guide anymore. Thanks for your notice, At first my receiver is DM800HD with second stage loader # 76 but i dont know is clone or not? When i turn on it appear on display dream multimedia sim2 and my friends told me it is clone.

Unfortunately after turning it on,doesn't work and Gemini project II startup page appears only!!! Wiimote whiteboard 13 download. Therefore i decided to change image and reloaded flash. My laptop doesn't have RS232 port therefore i connect laptop and DM to router and i browse DM ip address and upgrade firmware according to instructions on internet.a After too long nothing happened! Via telnet command i can do it with. Img file but i didn' t any image and flash and firmware file with. All of them are.nfi.

Please help me how could i upgrade And set newimage Regards. First up the latest bootloader for a dm800 clone is the 84d bootloader. To load it is simple.

Simply power off box, power it on again while holding the silver button. After a short while you get the message STOP and an IP address. Type the IP address into your browser and use the firmware upgrade option. Select the file and select the option to flash it. That said the problem you really have is that clone dm800 images are built on an archaic version of python. So you will be asked to load a wget command to load your providers IPTV bouquets.

It won't work as the version of WGET on these old images will not be able to process the wget command you receive. I have got around this by simply copying bouquets from a zgemmai55 running wooshbuild to my dm800 clone running openpli 3.0 using echanneliser, dreamboxedit is useless when it comes to IPTV.
